Tipe mesin | Air Cooled 4-Stroke,SOHC |
Susuan silinder | Single Cylinder |
Diameter langkah | 52,4 x 57,9 mm |
Perbandingan kompresi | 9,5 : 1 |
Volume silinder | 125 cc |
Daya maksimum | 7,0 kW / 8000 rpm |
Torsi maksimum | 9,5 Nm/ 5500 rpm |
Sistem starter | Electric & Kick Starter |
Sistem pelumasan | Wet Sump |
Kapasitas oli mesin | Total = 0,84 L ; Berkala = 0,80 L |
Sistem bahan bakar | Fuel Injection |
Tipe kopling | Single dry clutch |
Tipe transmisi | Full Automatic |
Kapasitas bahan bakar | 4,2 L |
Tipe rangka | Underbone |
Suspensi depan | Telescopic Fork |
Suspensi belakang | Unit Swing |
Ban depan | 100/90 - 12M/C 59J - Tubeless |
Ban belakang | 110/90-12M/C 64L - Tubeless |
Rem depan | Single Disc Brake |
Rem belakang | Drum Brake |
P x L x T | 1905 x 690 x 1100 (mm) |
Jarak Sumbu Roda | 1275 mm |
Tinggi Tempat Duduk | 778 mm |
Berat Isi | 100 Kg |
Kapasitas Tangki Bensin | 4,2 L |
Sistem pengapian | TCI / Transistor |
Battery | YTZ4V |
Tipe busi | CR6HSA |
